| General | |
| Numar porturi |
8x RJ-45
|
| Porturi |
8x RJ45
2x SFP 1x Console |
| Viteza de transfer |
10/100/1000 Mbps
|
| Alimentare |
100-240VAC, 50/60Hz
|
| Dimensiuni |
294 x 180 x 44 mm
|
| Memorie Buffer |
512KB
|
| Adrese MAC |
8k
|
Specificatii
| LAN-Port-Type |
Gigabit |
|---|---|
| Management |
Managed |
| PoE |
Nu |
| Storage temperature (T-T) |
-40 – 70 °C |
| Storage relative humidity (H-H) |
5 – 90% |
| Product colour |
Black |
| Quick start guide |
Yes |
| LED indicators |
Yes |
| Operating temperature (T-T) |
0 – 40 °C |
| Jumbo frames support |
Yes |
| Link aggregation |
Yes |
| Height |
44 mm |
| Power supply included |
Yes |
| User guide |
Yes |
| Operating relative humidity (H-H) |
10 – 90% |
| Rack mounting |
Yes |
| VLAN support |
Yes |
| Quality of Service (QoS) support |
Yes |
| Static route |
Yes |
| Web-based management |
Yes |
| System event log |
Yes |
| Switch type |
Managed |
| Port mirroring |
Yes |
| Form factor |
1U |
| Firmware upgradeable |
Yes |
| MAC address filtering |
Yes |
| Width |
294 mm |
| Depth |
180 mm |
| Access Control List (ACL) |
Yes |
| Power over Ethernet (PoE) |
No |
| Basic switching RJ-45 Ethernet ports type |
8 |
| Flow control support |
Yes |
| Rate limiting |
Yes |
| IGMP snooping |
Yes |
| Rack mount kit |
Yes |
| Power source |
AC |
| Installed SFP modules quantity |
0 |
| Switch layer |
L2+/L3 |
| Configuring Location Settings (CLI) |
Yes |
| 10G support |
No |
| Broadcast storm control |
Yes |
| Spanning tree protocol |
Yes |
| Multicast support |
Yes |
| MAC address table |
8000 entries |
| Jumbo frames |
9000 |
| Fanless |
Yes |
| IP routing |
Yes |
| Number of VLANs |
4000 |
| SSH/SSL support |
Yes |
| Loop protection |
Yes |
| GARP VLAN Registration Protocol (GVRP) |
Yes |
| Cloud-managed |
Yes |
| Authentication type |
RADIUS |
| ARP inspection |
Yes |
| Switching capacity |
20 Gbit/s |
| Packet buffer memory |
4.1 MB |
| BPDU filtering/protection |
Yes |
| Store-and-forward |
Yes |
| Head-of-line (HOL) blocking |
Yes |
| Static port security |
Yes |
| Number of IP interfaces |
16 |
| DHCP features |
DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping |
| IP-MAC-Port binding |
Yes |
| Authentication |
MAC-based authentication, Port-based authentication |
| Multicast Listener Discovery (MLD) snooping |
Y |
| Management protocols |
SNMPv1/v2c/v3, SNTP |
| IPv4 routes |
48 |
| IPv6 routes |
48 |
| IPv4 & IPv6 features |
IPv4/IPv6 access-control list (ACL), IPv6 Telnet, IPv6 ping, IPv6 tracert |
| MIB support |
Yes |
| Virtual LAN features |
Port-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN |
| Forwarding rate |
14.9 Mpps |
| Minimum system requirements |
Microsoft® Windows® 8, 7,Vista™, XP or MAC® OS, NetWare®, UNIX® or Linux. |
| Power consumption (max) |
6.84 W |
| Heat dissipation |
23.33 BTU/h |
| Porturi RJ 45 |
5-10 |
| Viteza transfer |
Gigabit |
| Porturi SFP |
1-2 |
| Montare in rack |
Nu |
| SFP module slots quantity |
2 |
| Console port |
RJ-45/micro-USB |
| Producator |
TP-LINK |
| Garantie |
24 |
